CAT-IR 模組底座
- AT等級 : AT3+
- 表面硬化硬度 : HRC 56 ± 2
- 偏擺 : 0.003mm(0.00012")
- 動平衡等級 : G6.3 25000 rpm Option to G2.5 25000 rpm
| 產品名稱 | D | L | 詢價數量 | |
|---|---|---|---|---|
| CAT40 IR08-2.82"-EX | 0.47" | 2.055" |
|
|
| CAT40 IR8S-2.82"-EX | 0.63" | 2.055" |
|
|
| CAT40 IR11-4.00"-EX | 0.75" | 2.622" |
|
|
| CAT40 IR16-4.00"-EX | 1.10" | 1.874" |
|
|
| CAT40 IR20-4.00"-EX | 1.34" | 1.835" |
|
|
| CAT40 IR25-4.00"-EX | 1.66" | 1.559" |
|
|
| CAT40 IR32-4.72"-EX | 1.97" | 2.146" |
|
|
| CAT40 IR32-4.72"-EXG | 1.97" | 2.146" |
|
|
| CAT40 IR40-4.72"-EX | 2.48" | 1.988" |
|
|
| CAT50 IR08-2.82"-EX | 0.47" | 2.055" |
|
|
| CAT50 IR8S-2.82"-EX | 0.63" | 2.055" |
|
|
| CAT50 IR11-4.00"-EX | 0.75" | 2.622" |
|
|
| CAT50 IR16-4.00"-EX | 1.10" | 1.874" |
|
|
| CAT50 IR20-4.00"-EX | 1.34" | 1.835" |
|
|
| CAT50 IR25-4.00"-EX | 1.66" | 1.559" |
|
|
| CAT50 IR32-4.00"-EX | 2.75" | 1.421" |
|
|
| CAT50 IR32-4.00"-EXG | 2.75" | 1.421" |
|
|
| CAT50 IR40-4.13"-EX | 2.75" | 1.398" |
|
